Designs

Architectural Design Experience

Residential Building in Gujur, Varthur Taluk, Bangalore

Residential Building in Gujur, Varthur Taluk, Bangalore

Residential Building in BDA-Arakavathi Layout, Bangalore

Residential Building in BDA-Arakavathi Layout, Bangalore

Residential Building in Tirupur, Coimbatore Dist. TN

Residential Building in Tirupur, Coimbatore Dist. TN

Hotel at Vandayar, Coimbatore Dist. TN

Hotel at Vandayar, Coimbatore Dist. TN

Strl. Design Experience (Overseas)

  • Industrial Building for UNIVERSAL COILS & HEAT EXCHANCHANGE INDUSTRIES. JEDDAH with crane capacity of 5T, 10T, 20T and 25T with the cold form Standard Sections, office Building with mezzanine office floor Building.
  • SPECIAL POLES AS H-Frame structures for SEC Western Region, KSA: The SEC Special Poles designed as per 20 SDMS 02 for basic Span of 100m to 400m. The height of the Frame and for single pole is 16 to 30m for valley & Road crossing. Based on the SEC specification 20 SDMS 02 and same load factors are used. The SAG & TENSION were determined by PLS CAAD and then used in PLS Pole Line Design Software.
  • Over Head Line Design for Ministry of Electricity, Damuscus, Syria, of the 66.0 KV single Circuit and Double Circuit Line, basic span 250m and 200m for five Categories as Normal Suspension (0-2D), with Ext. (3+6+9.0) m, Small Angle Poles (3-30D) with Ext. (3+6)m, Big angle Poles (31-60D) with Ext. (3-6)m, Dead End Pole (90D) Perpendicular, and Dead End Pole (0-45D) with Ext. (3+6)m.
  • Design of Stadium polygonal High Mast for Ministry of Youth Affairs, Jeddah, for 30.0 and 35.0m Ht to carry 36 # 2000W Flood lights with platform, and Foundation Design and detailed drawings with non-linear Analysis is carried out as 3D model with wind speed of 160km/hr and 3 sec Gust factor for return period of 25 years as per ILE report – 7.
  • CARREFOURE HYPER SHOPPING MALL, Riyadh: The Project has basement & FF Car parking + G + Four Story Structure.

Strl. Design Experience (Indian Project)

Commecial Bdgs in Aligargh

Commecial Bdgs in Aligargh

Bldg at Palwal, Haryana

Bldg at Palwal, Haryana

Khurja Medical College Auditorium UP

Khurja Medical College Auditorium UP
